Cylinder Mounting Parts & Accessories

Festo Cylinder Mounting Parts & Accessories

Festo offers a comprehensive range of mounting hardware and accessories that support pneumatic cylinders, providing machine designers with modular solutions for secure attachment, sensor integration, position sensing, shock absorption and system optimization. These accessories help ensure actuators are mounted correctly, aligned accurately and maintained efficiently for optimum lifecycle performance.

⭐ Important: Mounting parts and accessories play a critical role in actuator performance, affecting alignment, force transmission, lifetime, and machine reliability.

Design & Functionality

• Mounting Elements: Flanges, foot mounts, pivot mounts, clevis brackets and trunnions enable the cylinder to be securely attached in any orientation and machine layout.
• Guidance & Brackets: Support structures for guided cylinders and rodless actuators improve stability, reduce wear, and maintain alignment under heavy loads and high cycle rates.
• Position Sensing Options: Magnetic pistons or sleeves, proximity sensor slots, and sensor kits enable precise rod/cylinder position feedback and automation control.
• Cushioning & Damping Kits: Adjustable cushions, shock absorbers and end-stop modules help protect actuator ends, reduce impact noise, and prolong seal and bearing life.
• Accessory Integration: Various tubing clamps, port adapters, mounting interface kits and connection blocks simplify installation and save time during machine build-out.
• These components are engineered for high compatibility with cylinder types, adhere to ISO standards, and support modular assembly and quick field maintenance.

⭐ Important: Proper selection of mounting accessories ensures correct cylinder alignment, reduced wear, and longer actuator service life.

Total Crossed Beams

(Adapted concept: full coverage of mounting and accessory support rather than literal beams)

• The accessory range ensures coverage of all cylinder mounting needs: mechanical, sensor integration, cushioning, and modular customization.
• This broad support ensures complete system reliability and optimized actuator performance across diverse applications.

Beam Pitch Options

(Translated as: variety of accessory types, sizes and compatibility levels)

• Mounting accessories available for cylinder bore sizes from 8 mm to 100 mm+ and guide systems.
• Sensor kits and piston magnets for all cylinder families: ISO, compact, round, and rodless.
• Cushioning kits adjustable for stroke lengths from 10 mm to 500 mm, depending on cylinder model.
• These options allow machine designers to select the exact accessory combination for cylinder type, machine layout and environment—offering high installation flexibility.

⭐ Important: A wide selection of accessory types ensures that every actuator type is supported, from standard and compact to rodless and guided cylinders.

Intrinsic Synchronism

• Accessory systems are designed to seamlessly integrate with cylinder mechanics, ensuring sensors, mounts and cushions align and operate in sync with the actuator’s motion.
• This results in optimum machine coordination, minimal setup time, and high reliability without extra alignment or retro-fit effort.

Operational Advantages

• Secure and precise mounting, reducing misalignment and wear
• Modular accessory setup, simplifying machine build and maintenance
• Integration of sensors and cushions, improving control and lifetime
• Wide compatibility across cylinder families
• Applications: Machine builders, pneumatic system integrators, packaging equipment, automated assembly lines, rodless systems, conveyor drives—where correct mounting and accessory integration matter for performance.
